MELVILLE, N.Y. – Comtech PST Corp. in Melville, N.Y., is introducing the mannequin BME69189-100 small-form-factor solid-state energy amplifier module for changing touring wave tubes (TWTs) and microwave energy modules (MPMs) in legacy aerospace and protection electronics.
The built-in RF gallium nitride (GaN) mannequin BME69189-100 gives 6 to 18 GHz at 100 Watts, and is for communications, digital warfare (EW), and radar transmitter techniques the place area, cooling, and energy are restricted.
The RF GaN solid-state energy amplifier module presents extremely wideband operation; full energy throughout your entire bandwidth; is rugged and dependable; is compact and light-weight; presents low harmonic distortion; has low-voltage operation; tolerates tender failure with swish degradation; presents built-in RF energy reporting; and operates with 28- or 270-volt DC enter.
Associated: Gallium nitride (GaN) RF and microwave amplifier for communications functions launched by Empower RF
The ability electronics gadgets presents AB linear operation; most enter and output voltage standing wave ratio (VSWR) of two.0 to 1; will output energy into 2:1 load of greater than 70 Watts; presents over-current fault built-in check; operates at lower than 30 Watts DC and standby energy; presents typical effectivity of 10 p.c; and makes use of SMA Feminine subject replaceable connectors for enter and output.
These energy modules function at baseplate temperatures from -40 to 75 levels Celsius; resist the consequences of shock and vibration per MIL-STD-810F; measure 8 by 6 by 2.5 inches; and weigh 5.5 kilos.
For extra info contact Comtech PST on-line at https://comtechpst.com.
